Features: It is convenient to replace molds for different operations and improve work efficiency.
Uses: It can punch, cut, bend, bend pipe and other operations.
| Model | Functions | Voltage | Working Pressure (MPa) | Cutting Capacity (T) | Punching Capacity (T) | Bending Capacity (T) | Weight (kg) | Cutting Ability (mm) | Horizontal Bending Ability (mm) | Vertical Bending Ability (mm) | Bending Ability |
| KET-JGJ-3 | Cutting, Punching Horizontal bending | Single phase 220V 50Hz | 70 | 25 | 30 | 15 | 15 | Cu/AI: 150×12 | Cu/AI: 150×12 | / | / |
| KET-JGJ-4 | Cutting, Punching Horizontal bending, Vertical bending | Single phase 220V 50Hz | 70 | 25 | 30 | 25 | 153 | Cu/AI: 150×12 | Cu/AI: 152×16 | Cu/AI: 125×12 | / |
| KET-JGJ-5 | Cutting, Punching, Horizontal bending, Vertical bending, Bending | Single phase 220V 50Hz | 70 | 25 | 30 | 25 | 160 | Cu/AI: 150×12 | Cu/AI: 152×16 | Cu/AI: 125×12 | 3” |
| Model | Punching Thickness (mm) | Standard Punching Dies (mm) | Bending Dies | Platform Size (mm) | Optional Accessories (mm) |
| KET-JGJ-3 | 4-13 | Φ10.5, Φ13.5, Φ17.5, Φ20.5 | / | 910×600×1000 | Φ8.5, Φ11.5, Φ15.5, Φ18.5punching die |
| KET-JGJ-4 | 4-13 | Φ10.5, Φ13.5, Φ17.5, Φ20.5 | Horizontal bending mould 1 piece, Vertical bending mould base 1set, Vertical bending mould 8 pieces （40-80×4, 40-80×5, 40-80×6, 40-80×8, 40-80×10, 100×10, 100-125×10, 120-125×12）, Vertical bending supporting block 6pieces（4, 5, 6, 8, 10, 12） | 910×660×1100 | Φ8.5, Φ11.5, Φ15.5, Φ18.5punching die |
| KET-JGJ-5 | 4-13 | Φ10.5, Φ13.5, Φ17.5, Φ20.5 | Horizontal bending mould 1 piece, Vertical bending mould base 1set, Vertical bending mould 8 pieces （40-80×4, 40-80×5, 40-80×6, 40-80×8, 40-80×10, 100×10, 100-125×10, 120-125×12）, Vertical bending supporting block 6pieces（4, 5, 6, 8, 10, 12）, Bending mould 7 pieces（1⁄2, 3⁄4, 1, 1⁄2, 2, 2⁄2, 3） | 910×7600×1160 | Φ8.5, Φ11.5, Φ15.5, Φ18.5punching die |
