Synchronous Lifting Hydraulic System for Synchronous Jacking and Installation of Nuclear Fusion Dewar Bases
Publication date: 2021-07-12
  • Apps: Nuclear Power plant
  • Used: Synchronous Lifting Hydraulic System
The installation precision of the 1,250-ton Dewar base broke the record for heavy equipment installation in China's nuclear energy industry.
The installation precision of the 1,250-ton Dewar base broke the record for heavy equipment installation in China's nuclear energy industry.

Congratulations to China National Nuclear Corporation (CNNC) on the successful implementation of another major overseas project. The installation precision of the 1,250-ton Dewar base has set a new record in the nuclear energy industry. Jiangsu Kaint provided three sets of high-precision smart synchronous lifting hydraulic systems for this project, continuing our expansion into international markets alongside China's nuclear power initiatives.

—— On-site Operations ——

The installation of the 1,250-ton Dewar base was a project of significant complexity, requiring high installation precision and advanced measurement technology. The Chinese project management and construction techniques received high praise from the international nuclear energy organization, marking a major step forward for China's nuclear power sector into the high-end market. The installation precision also set a new record for large-scale equipment installation within China's nuclear energy industry.

Dewar Base Hoisting and Installation
Dewar Base Hoisting and Installation
Dewar Base Hoisting and Installation
Dewar Base Hoisting and Installation

During the severe period of the pandemic, Jiangsu KIET went "against the tide" to work overseas, managing both epidemic prevention and production. In the two months leading up to the installation, we collaborated with the contractor to conduct repeated technical verifications and reviews of the lifting plan. Under the guidance of renowned domestic experts, the plan was rehearsed, and on-site simulations and validations were conducted multiple times to identify potential issues and develop corresponding solutions and emergency plans.

KIET Synchronous Lifting Hydraulic System During On-site Testing
KIET Synchronous Lifting Hydraulic System During On-site Testing
KIET Synchronous Lifting Hydraulic System During On-site Testing

The significant importance of the Dewar base installation was mentioned multiple times. KIET fully recognized the critical nature of this project and made thorough preparations to face the task with complete confidence. When the 1,250-ton Dewar base was safely lowered onto the temporary supports inside the Tokamak device's foundation pit, the installation was successfully completed. This marked the beginning of the main equipment installation for the International Thermonuclear Experimental Reactor (ITER).

KIET's Synchronous Lifting Hydraulic System for Synchronous Jacking and Installation of Dewar Bases
KIET's Synchronous Lifting Hydraulic System for Synchronous Jacking and Installation of Dewar Bases
KIET's Synchronous Lifting Hydraulic System for Synchronous Jacking and Installation of Dewar Bases
KIET's Synchronous Lifting Hydraulic System for Synchronous Jacking and Installation of Dewar Bases

Once again, KIET's smart synchronous lifting hydraulic system demonstrated its exceptional performance by successfully completing a pre-determined high-precision lifting and installation task on a major international engineering project. We received full recognition from our international partners. We will continue to provide global customers with safe, high-quality, and efficient smart synchronous jacking, pushing, and pulling hydraulic systems and engineering solutions, safeguarding major engineering projects worldwide.
